RECEPTACLE 20AMP 125VAC 2P3W HUBBELL HBL2310

HBL2310

MANUFACTURER: HUBBELL

DESCRIPTION:
HUBBELL TWIST-LOCK SINGLE RECEPTACLE
20AMP 125VAC 2-POLE 3-WIRE
NEMA L5-20
HIGH IMPACT, ABUSE RESISTANT NYLON FACE
ALL BRASS GROUNDING & MOUNTING SYSTEM FOR LOWER RESISTANCE GROUND PATH & GREATER RESISTANCE TO CORROSION
FACE COLOR CODING BY VOLTAGE
WIRE RESTRAINT RECESS FOR BOTH BACK & SIDE WIRING
GLASS REINFORCED THERMOPLASTIC POLYESTER BASE
ONE PIECE CONTACT WITH LONG SPRING ARM
#10 SILICON BRONZE TERMINAL SCREW PROVIDES GREATER STRENGTH & RESISTANCE TO CORROSION & STRIPPING

APPROVALS:
UL LISTED
CSA LISTED
UL FED SPEC
IP20 SUITABILITY

WEIGHT: .272 LBS.
